COMPACT 24 with Auto Turn
Reviews
Find Your local dealer
Warranty Info
Financing Info
  • Specs
  • Downloads
  • Reviews

COMPACT 24 WITH AUTO TURN

( Remove )

Add Model to Compare

Title

COMPACT 24 WITH AUTO TURN

Model Number

920029

STAGE TYPE

Two Stage

CLEARING WIDTH (IN/CM)

24 In / 60.9cm

ENGINE BRAND

Ariens AX®

ENGINE POWER

10.0 lb / 10.0 kg

STARTING SYSTEM

120v / Electric

HOUSING HEIGHT

20 In / 50.7cm

THROWING DISTANCE

3 ft - 40 ft

CHUTE TURNING RADIUS

205

DEFLECTOR CONTROL

In-Dash Lever

TIRE SIZE

15.0 In / 38.1cm

TIRE TYPE

Directional Snow Tread

STEERING

Auto-Turn

DRIVE TYPE

Disc-O-matic

SPEEDS

6 Forward/2 Reverse

LENGTH

53.3 In / 135.3cm

WIDTH

26.4 In / 67.0cm

HEIGHT

44 In / 111.7cm

WEIGHT

187 lb / 84.8 kg

GEAR CASE

Cast Iron

GEAR CASE WARRANTY

5 Year Consumer, 1 Year Commercial

IMPELLER PROFILE

Steel 3 Blade

IMPELLER DIAMETER

12 In / 30.4cm

AUGER DIAMETER

11 In / 27.9cm

AUGER TYPE

Steel Serrated

SKID SHOES

Steel Reversible

SCRAPER BAR

Steel Adjustable

PRODUCT WARRANTY

3 years residential use. 90 days commercial use

CHUTE ROTATION

2.5x Quick Turn

FEATURES AT A GLANCE

Light Type: Halogen
Handwarmers: Optional
Remote Deflector Control: Standard
Drift Cutters: Optional
One Hand Interlock: Standard

Show Advanced Specs

Add Another Model

Compare
Reviews
Thank you for your review!
It looks like you’re not completely satisfied with your experience.
If you would like to report your concerns and have our customer support team follow-up with you, please visit our customer support portal.

Accessories

Composite Skid Shoe Kit

Constructed of durable polyurethane material, the Ariens OEM Non-Abrasive Skid Shoes resist wear while providing protection from scratching and marring of decorative surfaces.

  • Part Number: 72603100

Steel Skid Shoe Kit

Prolong the life of the housing and scraper blade on your Ariens snow blower with an OEM Steel Skid Shoe Kit. Ariens engineered with steel material to resist wear and helps to protects pavement from scratching and marring. Includes mounting hardware.

  • Part Number: 72101100

Handwarmer Accessory Kit

Maintain precise control in the harshest of winter conditions with the Ariens OEM heated handgrips. These easy to install handgrips feature an ergonomic design for comfort with sure-grip technology so your gloves maintain their grip.

  • Part Number: 72101400

Snow Blower Maintenance Kit

This OEM snow blower maintenance kit is made to be used on Ariens Classic and Compact models. This OEM kit will help to keep your Ariens snow blower performing at industry leading levels by completing routine maintenance using these factory authorized parts and products.

  • Part Number: 72000800

Drift Cutter Kit (Black)

Chop through heavy snow drifts with the Ariens Drift Cutters. These cutter bars rotate down for regular use and help to direct snow into the auger housing for prompt discharge. This design allows for easy installation.

  • Part Number: 73203100

Snow Cab Kit

The Ariens snow cab kit attaches to any Ariens 2-Stage snow blower to provide the user with protection from wind and snow blowback. The cab enclosure offers front, side and top protection while operating your snow blower.

  • Part Number: 72102600
